Fully Automatic High Speed 4 Spindles 2 Lines Stretch Film Re-Winder (Industrial Type) / SIWCR-500-L2

Classification : Stretch Re-winder
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
Video Inquiry Now
  • Computer control over the entire process
  • From film roll to final pruduct, one process flow
  • Automatically core changing system
MODEL SIWCR-500-L2
Finished Roll Dia Ø 160 mm
Available Mother Roll Width 300 mm - 500 mm x Ø 750 (max)
Material Thickenss 0.010 - 0.018 mm
Finished Product Core Dia (outter) Ø 25 - 75 mm
Max Product speed 500 meter / min / line
Dimension L x W x H 2720 x 1920 x 1980 mm
Packing L x W x H 2920 x 2120 x 2080 mm
Power 220V, 3Phases, 50/60HZ, 12KVA
Weight 1850 kg(net) / 2000 kg(gross)
Required Air Compressor 3HP (not included)

* The specification are subject to be changed for improvement without notice.
