Classification : Stretch Blow Molding
Country: Taiwan
Phone: 886-4-22332281
Fax: 886-4-22306247
Contact Person: Sales Department
•Mold clamping by servo motor
•Stretch system by servo motor
•Preform carriage by servo motor
•Pitch change by servo motor
•Heating Oven rotation by servo motor
•PLC & HMI Control
•Standard Power regulator for control system
•Stretch system by servo motor
•Preform carriage by servo motor
•Pitch change by servo motor
•Heating Oven rotation by servo motor
•PLC & HMI Control
•Standard Power regulator for control system
Model | CMS-LL2 | CMS-LM8 | CMS-LS12 | ||
Container | Production capacity | pcs/hr | 5,000~7,200 | 7,000~9,600 | 9,000~12,000 |
Max. neck diameter | mm | Ø38~45 | Ø28~38 | Ø28~30 | |
Max. container height | mm | 350 | 320 | 250 | |
Max. body diameter | mm | Ø180 | Ø100 | Ø65 | |
Max. bottle capacity | ml | 6000 | 1500 | 600 | |
No. of cavities (mould) | no. | 2 | 8 | 12 | |
Heating oven | No. of ovens | sets | 4 | 4 | 8 |
No. of infrared heaters in each oven | pcs | 10 | 9 | 6 | |
Heating load (max.) | kw | < 72 | < 96 | < 96 | |
Air pressure | Low pressure | kg/cm2 | 7 | 7 | 7 |
m 3/min | 1 | 1 | 1 | ||
High pressure | kg/cm2 | up to 35 | up to 35 | up to 35 | |
Cooling water | Cooling capacity | kcal/h | 30000 | 30000 | 30000 |
Water consumption | l/min | 160 | 160 | 160 | |
Water temperature | °C | 8~12 | 8~12 | 8~12 | |
Pressure | bar | 4 | 4 | 4 | |
Total consumption power | kw | < 120 | < 110 | < 110 | |
Machine weight | ton | 7.5 | 12 | 12 |
* All Specifications and designs are subject to change without notice.
