Classification : GLOVE MAKING MACHINES
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
- Computer control over the entire process
- Jumbo film roll to final pruduct ( 2 line output ) , one process flow
- Automatically stop when running out of film / film feeding blocks or jam
- Automatically tear off the waste edge film
- Melting cut-off ( no cutting knife ) system save time and manpower on adjusting knife
- Capable to produce 3 types in same machine
MODEL | SSD - 800 - HGL |
---|---|
Production Size |
Length : 350 mm ( max ) Width : 350 mm ( max ) Thickness : 10 ~ 25 um |
Production Speed |
150 pcs / min x2 line |
Film Roll Size | Ø 1000 x 720 mm |
Power | 220 V, 3 Phases, 50 / 60 HZ, 20 KVA |
Heat | 9KW |
Dimension | L : 8500 mm W : 1700 mm H : 1800 mm |
Air Compressor | 6 HP ( not included ) |
