- Mold clamping by servo motor
- PLC & HMI Control
- Stretch system by servo motor
- Preform carriage by servo motor
|
Model |
CMS-1C |
CMS-2C |
||
|
Container |
Production capacity |
pcs/hr |
360~600 |
1200~1800 |
|
Max. neck diameter |
mm |
Ø17~73 |
Ø24~38 |
|
|
Max. container height |
mm |
250 |
300 |
|
|
Max. body diameter |
mm |
Ø120 |
Ø95 |
|
|
Max. bottle capacity |
ml |
800 |
1500 |
|
|
No. of cavity |
no. |
1 |
2 |
|
|
Heating oven |
No. of oven |
no. |
1 |
4 |
|
NO. of infrared heaters in each oven |
no. |
6 pcs * 1000 kw |
8 pcs * 1000 kw |
|
|
Heating load (max.) |
kw |
< 25.6 |
< 64 |
|
|
Air pressure |
Low pressure |
kg/cm2 |
7~10 |
7~10 |
|
High pressure |
kg/cm2 |
up to 35 |
up to 35 |
|
|
Cooling water |
Cooling capacity |
kcal/h |
12000 |
18000 |
|
Water consumption |
l/min |
80 |
80 |
|
|
Water temperature |
°C |
8~12 |
8~12 |
|
|
Pressure |
bar |
3 |
2 |
|
|
Total consumption power |
kw |
< 30 |
< 52~72 |
|
|
Machine dimension |
m |
2.0x1.5x2.05 |
4.1x2.0x1.8 |
|
|
Machine weight |
ton |
3 |
6 |
|
* All Specifications and designs are subject to change without notice.
