Classification : Side Sealing Bag Making Machines
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
- Computer control over the entire process
- Servo motor, as standard attachment, makes it easy to adjust the bag length and the production speed
- Component self-testing function available
- Automatic film feeding, coordination free from tension adjustment
- Automatically stop when running out of film
- Automatically stop when film feeding blocks or bags jam
- High production efficiency to save manpower and time
| MODEL | SH-32-FC |
|---|---|
| Bag Length | 50 - 550 mm |
| Bag Width | 700 mm (max) |
| Film Thickness | 0.010 - 0.050 mm |
| Production Speed | 60 - 250 / min |
| Upload Film Roll Dia | Ø750 mm x 700 mm |
| Power | 220V,3Phases,50/60HZ,10KVA |
| Heater | 2KW |
| Dimension L x W x H | 5240 x 1370 x 2090mm |
| Packing L x W x H |
3150 x 1610mm 2610 x 1850mm |
| Required Air Compressor | 5HP (not included) |
| Weight |
7000kg (net) / 7800kg (gross) |
