Fully Automatic High Speed Single Line Coreless Bag on roll Making Machine / SSR-40-L1+2T

Classification : Bag-on-roll Making Machines
Country: Taiwan
Phone: 886-2-86782865
Fax: 886-2-86782869
Contact Person: Yarzar
Inquiry Now
  • Computer control over the entire process
  • From film roll to final pruduct, one process flow
  • Automatic film feeding, cordination free from tension adjustment
  • Automatically stop when running out of film / color scanning error / film feeding blocks or jam

MODEL SSR-40-L1+2T
Length 250 ~ 1500 mm
Width 70 ~ 90 mm
Thickness 8 ~ 35 um
Production Speed 100 meters / min / line
Film Roll Size Ø 900 x 330 mm (max)
Power 220V, 3Phases, 50/60 HZ, 12KVA
Heater 2 KW
Dimension L8200 x W1500 x H1700 mm
Air Compressor 6 HP ( not included )
