Classification : Bag on roll Making Machines
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
- Computer control over the entire process
- From film roll to final pruduct, one process flow
- Automatic film feeding, cordination free from tension adjustment
- Automatically stop when running out of film / color scanning error / film feeding blocks or jam
- Oscillation film feeding system for stability and high out put
| Model | SOSR-1000-R |
| Bag length | 500 - 3000 mm |
| Bag Width | 300 - 900 mm |
| Film Thickness | 0.008 - 0.060 mm |
| Production Speed | 60 - 150 meter / min / line |
| Finished Roll (max, dia.) | Ø 900 x 900 mm |
| Power | 220V, 3Phases, 50/60HZ, 30KVA |
| Heater | 6.2 KW |
| Dimension L x W x H | 77330 x 1820 x 1600 mm |
| Packing L x W x H | Machine : 352 x 170 x 135 cm |
| Rewinder : 210 x 182 x 1800 cm | |
| Folder : 75 x 128 x 125 cm | |
| Required Air Compressor | 6HP (not included) |
The specification are subject to be changed for improvement without notice.
