Classification : Bag on roll Making Machines
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
- Computer control over the entire process
- From film roll to final pruduct, one process flow
- Automatic film feeding, cordination free from tension adjustment
- Automatically stop when running out of film / color scanning error / film feeding blocks or jam
MODEL | SIR-400-L2 |
Length | 250 ~ 1500 mm |
Width | 100 ~ 300 mm |
Thickness | 8 ~ 35 um |
Roll size | Ø 150 x 330 mm (max) |
Production Speed | 90 meters / min / line (max) |
Film Roll Size | Ø 900 x 550 mm (max) |
Power | 220V, 3Phases, 50/60 HZ, 20KVA |
Heater | 4 KW |
Dimension | L7000 x W2750 x H1950 mm |
Air Compressor | 6 HP ( not included ) |
