Classification : Bag on roll Making Machines
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
- Computer control over the entire process
- From film roll to final pruduct, one process flow
- Automatic film feeding, cordination free from tension adjustment
- Automatically stop when running out of film / color scanning error / film feeding blocks or jam
| MODEL | SIR-400-L2 |
| Bag Length | 250 - 1500 mm |
| Bag Width | 100 - 300 mm |
| Film Thickness | 0.008 - 0.035 mm |
| Production Speed | 90 meters / min / line (max) |
| Finished Roll Size | Ø 150 x 330 mm (max) |
| Upload Film Roll Dia | Ø 900 x 550 mm (max) |
| Power | 220V, 3Phases, 50/60HZ, 20KVA |
| Heater | 4 KW |
| Dimension L x W x H | 7000 x 2740 x 1950 mm |
| Packing L x W x H | Machine : 2440 x 1540 x 1950 mm Rewinder : 2300 x 2850 x 1700 mm Unwinder : 1610 x 1490 x 1450 mm |
| Required Air Compressor | 6HP (not included) |
| Weight | 4000kg (net) / 4600kg (gross) |
