Accumulative Extrusion Blow Molding Machine for Medium to Large Containers

Classification : Extrusion Blow Molding
Country: Taiwan
Phone: 886-4-22332281
Fax: 886-4-22306247
Contact Person: Sales Department
Inquiry Now
  • The accumulator head is screw type that have the lowest degradation of melt resin.

  • A specially-designed by pass circuit permits a very secure mold clamping effect.

  • The entire extruder can be adjusted automatically in an upward/downward direction through hydraulic power.
  • Model CM-45I CM-90I
    Model Material to be Used PE PE
    Screw Diameter mm Ø75 Ø90
    L/D Ratio 24/1 24/1
    Screw Speed Range (PE)/rpm rpm 15-65 15-65
    Inverter Motor HP - -
    Max. Extrusive Capacity/Hour kgs 70 110
    Heating Zone (Barrel) zone 3 3
    Heating Capacity (Barrel) kw 12 15.3
    Die head Heating Zone (Diehead) zone 3 4
    Heating Capacity (Diehead) kw 12 28.9
    Double Mold Center Distance mm - -
    Mold Plate Max. Opening Stroke mm 800 1000
    Min. Close Stroke mm 200 270
    Mold Clamping Force ton 20 30
    Hydraulic System Hydraulic Pump Motor HP 40 60
    Hydraulic Oil Pressure kg/cm2 140 150
    Oil Tank Capacity gallon 220 250
    Product Product Weight (Max.) g
    Product Dia. (Min./Max.) mm 100-320 120-480
    Product Capacity (Min./Max.) ml 10000-20000 15000-30000
    Total Power Consumption kw 57.6 92.7
    Weight of Machine ton 11 12

    * All Specifications and designs are subject to change without notice.

    * All models can be upgraded to hybrid or fully electric type by servo motor control.
