Classification : Garbage Bag & Industrial Bag Making Machines
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
- Computer control over the entire process
- From film roll to final pruduct, one process flow
- Servo motor, as standard attachment, makes it easy easy to adjust the bag length and production speed
- Automatically stop when running out of film / film feeding blocks or jam / scanning error
MODEL | SE - 40S |
---|---|
Production Size |
Length : 100 ~ 1500 mm
Width : 150 ~ 1000 mm |
Production Speed | 30 ~ 130 pcs / min / line |
Film Roll Size | Ø 900 x 1000 mm |
Power |
220V,3Phases,50/60HZ,12KVA |
Heater | 3 KW |
Dimension |
L : 5300 mm
W : 1850 mm |
Air Compressor | 5 HP (not included) |
MODEL | SE - 50S |
---|---|
Production Size |
Length : 100 ~ 1500 mm
Width : 150 ~ 1200 mm |
Production Speed | 30 ~ 130 pcs / min / line |
Film Roll Size | Ø 900 x 1200 mm |
Power |
220V,3Phases,50/60HZ,12KVA |
Heater | 3 KW |
Dimension |
L : 5600 mm
W : 2050 mm |
Air Compressor |
5 HP (not included) |
* The specification are subject to be changed for improvement without notice.
