Injection Blow Molding Machine PK-IBT Series

Classification : Injection Blow Molding Machine
Country: Taiwan
Phone: 886-4-23396828
Fax: 886-4-23394679
Contact Person: Sanni Yang
Inquiry Now

Features

  • HMI Touch Screen(Fuji-Japan), Incorporating with PLC system(Omron-Japan) for easy maintenance.
  • The machine provides fast molding performance without scrap or connecting lines on bottle bottom or side.
  • Maximum uniformity of bottle weight, thickness and volume.
  • Extremely smooth and elegant bottle surface is ideal for high-quality and high-price packaging.
  • This high production machine is capable of producing bottles in multiple cavities at one time.
  • Suitable for various materials, such as PET, PETG etc., for producing various types of bottles.
  • Multiple-stage injection.



Application

Cosmetic

Cosmetic

Cosmetic

Cosmetic / Personal care

Cosmetic

Cosmetic

Cosmetic
Cosmetic



  • Four-station Type
  • Production Volume:PET 2ml~20ml /PETG 2ml~120ml
  • Multi cavities: 1~12 cavities
  • Specialize for the PETG/PET
  • Driven Model: Hybrid servo motor drive system/ High performace hydraluic power saving system/Close loop proportional valve



MODEL UNIT

PK-30IBT

PK-55IBT

INJECTION UNIT
Screw Diameter mm ∅32 ∅40 ∅45 ∅50 ∅55 ∅60
L / D   22:1 22:1 22:1 24:1 24:1 24:1
Screw-speed Range RPM 0-120 0-120 0-120 0-120 0-120 0-120
Screw Stroke mm 150 150 200 250 250 250
Max. Shot-weight g 65 100 170 265 320 380
Plasticizing Capacity g/s 15 25 30 47 61 53
MOLD CLAMPING UNIT (INJECTION UNIT)
Injection Mold Opening Stroke mm 115 135
Injection Mold Clamping Force ton 30 55
Trigger Bar Length mm 335 735
Max Swing Radius mm 410 570
MOLD CLAMPING UNIT (BLOWING UNIT)
Blow Mold Opening Stroke mm 115 135
Blow Mold Clamping Force ton 5 10
POWER SYSTEM
Pump Motor HP 25 40
Pump Pressure kg/cm² 130 130
Heating Capacity kw 8 14
Heating Zone point 4 8
Air Requirement (Approx.) m/hr 30 30
Air Pressure bar 25 25
Oil Tank Capacity L 300 550
Total Power Consumption kw 27 44
Machine Dimension M 3.7x2.3x2.8 4.7x2.1x2.5
Machine Weight ton 5 10
Packing Size M 4x2.5x3.1 4.9x2.2x2.2
Machine Meas't 11.5 34

* All specifications and designs are subject to change without notice.
