Classification : PVC Shrinkable Label Making Machine
Country: Taiwan
Phone: 886-4-24832477
Fax: 886-4-24830852
Contact Person: Angela Chi
- Suitable for paper, plastic films.
- Perforation possible in straight and cross directions.
- Servo motor to maintain accuracy at 400 cuts per minute.
Model No. | ACDV-30S | ACDV-50S | |
---|---|---|---|
Max. Parent Web Width | 300 mm | 500 mm | |
Max. Parent Web Diameter | 800 mm | 800 mm | |
Max. Cutting Length | Plain film | 400 mm | 500 mm |
Printed Film | 300 mm | 400 mm | |
Max. Machine Speed | 400 Cuts / min. | 300 Cuts / min. | |
Installation Information (For Standard Specification) |
Net Weight | 600 kg | 1100 kg |
Area Required | L2395 x W1066 x H1415 (mm) | L2500 x W1310 x H1420 (mm) | |
Power | 380V / 3.6KW / 13A | 380V / 3.6KW / 13A | |
Water | X | X | |
Air | 6 kg / cm3 | 6 kg / cm3 |
