KET-100R All-Electric Injection Molding Machine

Classification : All Electric Injection Machine - KET Series

TAIWAN KINKI MACHINERY CO., LTD.

Country: Taiwan

Phone: 886-2-2281-3361

Fax: 886-2-2281-8206

Contact Person: Terry Hsieh

Inquiry Now

At Taiwan Kinki Machinery, we are proud to introduce our cutting-edge All-Electric Injection Molding Machine with Rotary Table, designed specifically to meet the growing demand for efficient and high-quality automotive parts molding. With its advanced features and superior performance, this state-of-the-art machine is poised to revolutionize the industry.

High Efficacy for Increased Productivity: Efficiency is at the core of our All-Electric Injection Molding Machine. By harnessing the power of advanced servo motor technology, we have achieved exceptional energy efficiency and rapid response times, resulting in heightened productivity. With precise control and fast cycle times, you can optimize your production output while maintaining the highest standards of quality.
Rotary Table for Enhanced Versatility: Our All-Electric Injection Molding Machine comes equipped with a revolutionary Rotary Table, providing unparalleled versatility in automotive parts molding and beyond. The Rotary Table allows for precise and simultaneous multi-component molding, ensuring superior product quality and consistency. With this innovative feature, you can now achieve complex geometries, multi-material combinations, and intricate designs with ease.
Low Noise: One of the standout advantages of our All-Electric Injection Molding Machine is its remarkably low noise level during operation. By utilizing cutting-edge technology and intelligent design, we have successfully reduced noise emissions to create a quieter production environment. This not only enhances the comfort and well-being of your operators but also contributes to a more sustainable and harmonious workplace.
Saving Water: All-electric injection molding machines eliminate hydraulic systems in hydraulic injection molding machines that use hydraulic oil to power their operations. This oil needs to be cooled to prevent overheating, which is typically done using water. In all-electric machines, the hydraulic system is eliminated, removing the need for water cooling.
Saving Power: All-electric machines utilize electric servo motors for each machine function, such as the injection, clamping, and ejection processes. These motors only consume electricity when actively performing a task and are highly efficient. In contrast, hydraulic machines continuously consume energy to maintain hydraulic pressure, resulting in higher energy consumption.

RELATED VIDEO

MORE INTRODUCTION
All Electric Vertical Injection Molding Machine, Fits Topics of K 2022
All Electric Vertical Injection Molding Machine for a More Eco-friendly Future
Automotive Injection Molding Machine Selection Guide

Machine Type	Unit	KR-85-D(R)		KR-110-D(R)		KR-150-D(R)
Screw Diameter	mm	20	25	25	30	30	35
Injection Pressure	kg/cm²	2500	1836	2500	1736	2500	1600
Theoretical Shot Volume	cm³	31	49	59	85	99	135
Max. Shot Weight(PS)	g	29	45	54	77	90	123
Injection Speed(High Loading Capacity)	mm/sec	200		200		200
Injection Speed(High Velocity)	mm/sec	270		270		270
Screw Stroke	mm	100		120		140
Screw Speed Max.	rpm	350		350		350
Nozzle Contact Force	tons	2		2.4		2.6
Nozzle Retraction Stroke	mm	200		250		280
Number of Temperature Control	-	3		3		4
Material Hopper Capacity	\|	20		20		30

Machine Type	Unit	KET-40R	KET-70R	KET-100R
Clamping Force	tons	40	70	100
Dimensions of Rotary Table	mm	1000	1200	1400
Mold Thickness	mm	170~270	230~350	250~400
Opening Stroke	mm	210	250	270
Ejector Force	tons	1.3	2.1	2.6
Ejector Stroke	mm	60	60	60

Machine Type	Unit	KET-40R	KET-70R	KET-100R
Heater Capacity	kw	2.7	3.5	4.5
Consumption	kw	14.6(30Ax380V)	18(50Ax380V)	20(75Ax380V)
Machine Weight	tons	3	4	7.5
Machine Dimensions(L x W x H)	m	-	-	-
