LD/LLDPE Super High Speed Inflation Machine (GF-L85ES)
Categories : Blown Film Extruders Lines
The GF-L85ES is the largest of the three GF-L ES super high speed blown film lines for LD and LLDPE film. It is specified for a maximum film width of 2200 mm and a maximum capacity of 240 KG/HR, using an 85 mm screw, a 100 HP driving motor and a 500 mm blown film die, with 8 ZONES of temperature control on the panel. The GF-L55ES and GF-L65ES cover the narrower widths in the same series. The tower fixed take-up unit has a 2300 mm roller width and runs at Max. 60 M/Min, and the single-station surface friction winder changes bobbins semi-automatically by pneumatic system. The same option list as the rest of the ES series applies, including stacked air ring, width control, corona treater, EPC or CPC edge control, oscillating take-up, double station winder, auto tension control, hydraulic unloading, heat-slitting, a second gusset unit, an in-line bag making or printing machine, and an edge-trim on-line re-use system for returning trim to the extruder. Material: LD/LLDPE Max. film width: 2200 mm Max. capacity: 240 KG/HR Extruder: 85 mm screw, 100 HP driving motor; 500 mm blown film die Temperature control: 8 ZONES Take-up: tower fixed type, 2300 mm roller width, Max. 60 M/Min Winding: single station surface friction type, semi-auto pneumatic bobbin change Options: stacked air ring, width control, corona treater, EPC/CPC, oscillating take-up, double station winder, hydraulic unloading, heat-slitting, in-line bag making/printing, edge-trim re-use
PLA/ PBAT Blown Film Machine
Categories : Blown Film Extruders Lines
The PLA/PBAT Blown Film Machine (GF-LB Series) is a blown film line configured for compostable and biodegradable resins based on PLA and PBAT. It produces tubular film from these compounds for downstream bag making, in the same way that JANDI'S GF-L series does for conventional polyethylene, and is listed in the showroom specification table as the GF-LB Series with film width and extruder size selected per model. The line is built from an extruder, a blown film die, an air ring, a take-up tower and a winder. Options include an auto loader, manual screen changer, pressure gauge, die rotating unit, corona treater, flying knife, second station winder, air shaft and air chiller. Film width, output and configuration are confirmed with the buyer at quotation; the specification table below lists the series range. Type: single-layer blown film machine, GF-LB Series Material: PLA/PBAT based compostable and biodegradable compounds Extruder, blown film die, air ring, take-up tower and winder Options: auto loader, manual screen changer, pressure gauge, die rotating unit Options: corona treater, flying knife, second station winder, air shaft, air chiller Film width and extruder size per model, confirmed at quotation
LD/LLDPE High Speed Inflation Machine (GF-L55)
Categories : Blown Film Extruders Lines
The GF-L55 is a single-layer blown film line for LD and LLDPE (low density and linear low density polyethylene). It sits in the middle of the GF-L series, which runs from the GF-L35 up to the GF-L65, and is configured for producing polyethylene film for bags and packaging at a maximum film width of 1000 mm. The extruder uses a 55 mm screw driven by a 40 HP motor with inverter control, feeding a 200 mm die fitted with a dual-lip air ring. Rated output is 90 KG/HR. The line is controlled from an independent switch board, and film is taken up on a 1100 mm roller width and wound on a single-station manual surface winder. Options include an auto loader, manual screen changer, pressure gauge, die rotating unit, corona treater, HDPE dies and air ring, flying knife, second-station winder, air shaft and air chiller, so the same base machine can be specified for HDPE or for downstream printing. Material: LD/LLDPE Max. film width: 1000 mm Extruder: 55 mm screw, 40 HP motor with inverter Die: 200 mm with dual-lip air ring Max. capacity: 90 KG/HR Roller width: 1100 mm; single-station manual surface winder Options: auto loader, manual screen changer, die rotating unit, corona treater, HDPE dies/air ring, 2nd station winder, air chiller
Mini blown film line single head type without installation
Categories : Blown Film Extruders Lines
Mini blown film line single head type without installation
A/B/C BFS Series Co-Extrusion Blown Film Line
Categories : Blown Film Extruders Lines
FKI offers one of the most advanced and adaptable blown film lines for various applications, such as shopping bags, vest bags, garbage bags, agricultural film, construction film, packaging film and lamination film, etc. The workable materials that can be used are such as LDPE , LLDPE, MLLDPE, and HDPE. The film production range is from 200mmto 7 meters in tubular width, and the production output rate is from40kg/hr to800kg/hr. Based on 30 years of experience, FKI is capable of offering blown film lines with reliability and versatility to meet different requirements from mono layer, double color, double layer, and three layer to four color designs.
A/B/A BFT Series Co-Extrusion Blown Film Line- Oscillating Tower Type
Categories : Blown Film Extruders Lines
Tubular lay flat width:From 40mm to 7 meter. -MONO LAYER, TWO LAYER, THREE LAYER & FIVE LAYER -SINGLE COLOR, DOUBLE COLOR, UP TO 4 COLOR.
A/B/A BFT Series Co-Extrusion Blown Film Line- Rotary Die Head
Categories : Blown Film Extruders Lines
A/B/A BFT Series Co-Extrusion Blown Film Line- Rotary Die Head
Biodegradable Blown Film Machine(GF-BC Series)
Categories : Blown Film Extruders Lines
The GF-BC Series is a blown film machine for biodegradable material. It extrudes PLA and PBAT based compostable and biodegradable compounds into tubular film for bag making and packaging, and is listed in JANDI'S showroom alongside the PLA/PBAT Blown Film Machine (GF-LB Series). Offered as a series, it lets extruder size and film width be matched to the intended product. As a blown film line it is built around an extruder, a blown film die, an air ring, a take-up tower and a winder. The model range of the GF-BC Series, its film width and output, and the options that apply to it are confirmed with the buyer at quotation. Type: blown film machine for biodegradable material, GF-BC Series Material: PLA and PBAT based compostable and biodegradable compounds Extruder, blown film die, air ring, take-up tower and winder Related JANDI'S listing: PLA/PBAT Blown Film Machine (GF-LB Series) Model range, film width, output and options confirmed at quotation
Single-Layer High-Speed Blown Film Machine
Categories : Blown Film Extruders Lines
Ultra-Wide Width, High-Output Solution for Agricultural Film Using Recycled Materials The KS-FLL150 Single-Layer High-Speed Blown Film Machine is a high-capacity blown film line developed by KUNG HSING Plastic Machinery for agricultural film applications.Engineered to process LD and LLDPE recycled materials, the KS-FLL150 combines high-speed extrusion, stable bubble cooling, and precise width control to deliver consistent film quality and reliable productivity, even at ultra-wide widths up to 3000 mm and thick-gauge conditions.
