AUTOMATIC HIGH-SPEED THREE SIDE SEALING BAG MAKING MACHINE

Classification : Bag Making

ASARI PLASTIC CORPORATION

ASARI PLASTIC CORPORATION
Country: Taiwan
Phone: 886-6-5933-566
Fax: 886-6-5933-567
Contact Person: Mr. Liang
Control System
Digital Control System
Film Feed Machine Three AC Servo Motor Drive System
Heat-Sealer Vertical Movement Mechanism Single AC Servo Motor Drive System
Seal Width

Cross Seal : 5-80mm

Longitude Seal : 5-60mm

Sealer Station Cross Seal : 5 Set Heating Station 3 Set Cooling Station

Longitude Seal : 3 Set Heating Station 3 Set Cooling Station
Zipper Unit : 2 Set Heating Station 2 Set Cooling Station

Sealer Bar

Cross Staling Bar : 3 Set

Longitude Sealing Bar : 3 Pcs

Cooling Knife

Cross Seal : 2 GroupsLongitude Seal : 3 Sets

Zipper Unit : 2 Sets

Heat-Sealer AC Servo Motor 3.5 KW (1 Set)
Feed AC Servo Motor 1.0 KW (3 Sets)
EPC Control 0.13 KW (1 Set)
Longitudinal Heat-Sealer 5 KW (5 Sets)
Zipper Heat-Sealer 5 KW (2 Sets)
Cross Heat-Sealer 5 KW (5 Sets)
Compressed Air 0.6 Mpa (6 kgf/cm²)
Cutting Knife 1 Set
Zipper Mould 1 Set
Stand-Up Mould 2 Sets
ø8mm Hole Punch Unit 2 Sets
Easy-Tear Perforation Unit 2 Sets
Heat-Sealer-620mm, 860mm, 640mm 1 Set / Each Size
Rubber Sheath 10 Sets
Selective Equipment
Automatic Slider Insertion
Varies Hole Punch Unit
CE Self Declaration Modification
