Classification : Plastic Inflation Machine
Country: Taiwan
Phone: 886-2-22856880
Fax: 886-2-22856883
Contact Person: Gina Kang
KPP-35
Film Width100-300 mm
Screw Dia.Ø 35 mm
Suitable MaterialP.P.
KPP-35 model High-speed PP Blown Film Extrusion Line
| MODEL | KPP-35 |
| SUITABLE MATERIAL | P.P. |
| FILM THICKNESS | 0.02-0.10 mm |
| FILM WIDTH RANGE | 300 mm |
| FILM OUTPUT | 12-18 kgs/hr |
| EXTRUDER UNIT | |
| SCREW DIAMETER/TYPE | Ø 35 mm |
| SCREW L/D RATIO | 28:1 |
| HEATING CAPACITY | 6 kw |
| AUTO THERMO CONTROL | 3 zone |
| BARREL COOLING FAN | 1/16 HP x 1 |
| DRIVING MOTOR | AC 10 HP + Inverter |
| DIE UNIT | |
| DIE DIAMETER | Ø120 mm |
| AIR RING DIAMETER | Ø200 mm |
| HEATING CAPACITY | 2.6 kw |
| AUTO THERMO CONTROL | 2 zone |
| COOLING BLOWER | 1 HP |
| WATER RING | 10 pcs |
| TAKE-UP UNIT | |
| TAKE-UP ROLLER | 400 mm |
| EFFECTIVE WIDTH | 300 mm |
| TAKE-UP MOTOR | AC 1/2 HP |
| TAKE-UP SPEED | 40 m/min |
| WINDING UNIT | |
| ROLLER WIDTH | 400 mm |
| WINDING WIDTH | 300 mm |
| WINDING MOTOR | DC 1／2 HP |
| MACHINE DIMENSION | 300x100x350 cm |
* Remark: The above machine specification and production range can be changed without any notice due to kind of different application.
