Automatic PP Woven Fabric Tubing Machine

Classification : Automatic PP Woven Fabric Tubing Machine

BOTHEVEN MACHINERY INDUSTRIAL CO., LTD.

Country: Taiwan

Phone: 886-5-5916970

Fax: 886-5-5916968

Contact Person: Frank Liu

Inquiry Now

General Performance:
a. Diameter of Unwinding Cloth: 1000 mm Maximum
b. Processing Flat Fabric Width: 640 - 1350 mm
c. Production Output: Max. 100 Meter / Minute
Un-Winding Section
a. Fabric Roll Lifting: Pneumatic Type.
b. Automatic Edge Position Control(EPC): Hydraulic Type, With 1 HP AC Motor.
c. Automatic Tension Control: Powder Brake With Controller
d. Air Shaft: 2 PCS, Enclosed.
e. Automatic Roll Changing System: Enclosed.
Tubular Forming & Extruder Pasting
a. Processing Flat Fabric Width:
*640 - 1350 mm
*740 -1150 mm Can Be Gusseted.
*640 - 740 mm Can Not Be Gusseted, But Can be Pasted.
b. Gusset Depth: 40 - 90 mm Adjustment.
c. Main Motor of Pasting Extruder: AC 7.5 HP, With Inverter Control.
Re-Winding
a. Winding Method: Surface Friction Type.
b. Winding Motor: AC 3 HP Motor with Inverter Control.
c. Rewinding Roll Press Roller: Pneumatic Type
d. Automatic Roll Changing System: Enclosed.
Power Consumption
a. Rated Power Capacity: 17 KW
b. Actual Power Consumption: 15 KW
Dimension ( L x W x H ) : 105,000 x 4,250 x 2,200 mm
Weight: 6,500KG
Spare Parts: 1 Lot (Free of Charge) for each machine
