One Layer HDPE LDPE LLDPE 800mm

Classification : Blown Film Machine

Applications: Others HDPE Plastic Films

POLYSTAR MACHINERY CO., LTD.

Country: Taiwan

Phone: 886-6-2730889

Fax: 886-6-2730887

Contact Person: Jack Lin

Blog Inquiry Now

● Monolayer (1 layer)
● Film Width from 200~800mm
● Extruder Dia: 40mm, 45mm, 55mm
● Material: HDPE, LDPE, LLDPE, Master batch, CaCO3
● Output: 15~50kgs/hr

Model Name	MB Blow Film Machine
Final Product	HDPE, LDPE, LLDPE Plastic Film
Application	Flexible packaging bags, T-shirt bag, garbage bag, shopping bag
Material used	HDPE, LDPE, LLDPE virgin raw material, recycled material, CaCO3 compound, biodegradable material, masterbatch and additives
Output range	15 ~ 50kgs/hr (depends on extruder size)
Film Layer	Mono Layer (One Layer)
Screw Diameter	40-55mm (customized)
Screw L/D	28/1,30/1 (customized)
Screw Material	SACM-465 or bimetallic
Width	200~800mm
Thickness	0.008~0.1mm
Optional Devices	Auto loader, masterbatch dosing system, rotary die head, bubble controller, corona treater, embossing roller, automatic winder, double winder
Delivery Time	60~75 days
Warranty	1 year
Technical Assistance	Engineers available to service machinery overseas

Model	MB40	MB45	MB55
Screw diameter	40mm	45mm	55mm
Max. width	400mm	650mm	800mm
Output	15~30 kgs/hr	30~40 kgs/hr	40~50 kgs/hr
Thickness	0.008~0.1mm	0.008~0.1mm	0.008~0.1mm
