High Speed 1+1 Ear-loop Face-Out Type Medical Mask Machine

Classification : Mask Making Machine

MING JILEE ENTERPRISE CO., LTD.

Country: Taiwan

Phone: 886-6-5783420

Fax: 886-6-5783347

Contact Person: Chris Chang

Inquiry Now

The MGA-MSK-400-S8 is a high-speed 1+1 ear-loop face-out type medical mask machine that converts non-woven and melt-blown fabric rolls into finished masks through nose wire insertion, ultrasonic welding, ear loop attachment, and cutting in one continuous operation. It draws material from four unwinding stations feeding non-woven and melt-blown materials, with a nose bridge flattening device supporting mask quality.

The ultrasonic welding device is Taiwan-made, and servo-controlled ear-loop cutting keeps pace with production speed. Eight servo motor sets drive the machine, and an automatic conveyor moves counted, stacked masks smoothly to packaging.

Model	MGA-MSK-400-S8
General Machine Specifications
Machine Dimension	4,500 (L) x 2,430 (W) x 1,988 (H) mm
Power Consumption	9 kw
Net Weight	800 kg
Power Input	220V, single phase
Servo Motor	8 sets
Machine Performance
Mask Size (machine is only able to produce 1 size)	175 x 95 mm or 145 x 95 mm
Output	65 - 95 pcs/min
