3D Filament Extrusion Line

Classification : Product

PITAC INT'L MACHINERY CO., LTD.

Country: Taiwan

Phone: 886-2-27227966

Contact Person: Jenny Chen

Inquiry Now

General information
Using Material	PLA / ABS
Filament diameter	1.75 mm +/- 0.05mm
Productivity	4kg / hr for PLA, 3.5kg for ABS
Line speed	24 M/min.
Winder	2 axis
Install Power	8 KW
Running power	4 KW
Occupation area	1M (W) x 6M(L) x 1.8M(H)
Power source	220V x 3 phase
Extruder
Screw diameter	25mm
Thermal control	5 zones with PID control
Screw rotation control	Siemens AC inverter duty motor with Danfoss inverter
Water cooling bath
Water bath material	Stainless steel
Water circulation	Available
Water removing unit	Available
In-line diameter checking
Type	Laser scan
Resolution	0.001mm
Take-off
Take-off roller speed control	Siemens AC inverter duty motor with Danfoss inverter
Winder
Winder speed control	Siemens AC inverter duty motor with Danfoss inverter
Tension control	Available
Line guider	Available
