Classification : Extrusion Blow Molding Machine
Country: Taiwan
Phone: 886-4-23396828
Fax: 886-4-23394679
Contact Person: Sanni Yang
Features
- This type of machines is a hydraulic-clamping blow molding machine; the economic and efficient models are excellent for producing small containers.
- High plasticizing capacity extrusion screw is designed to handle material variations.
- Plasticizing screw and barrel is precision machined from special nitrogen treated steel.
- Water cooling technology controls feed zone temperature.
- Chiller circulated hydraulically controlled blow-pin.
- When requiring both functions in a single machine, purchase the machine for PVC application and order the additional parts for conversion to PE application.
- The economic, efficient models are excellent for producing small containers.
Application
Cosmetic |
Cosmetic |
Cosmetic |
Cosmetic |
Cosmetic |
Toys |
Toys |
Toys |
- Single Station
- Single/Double Head
- Production Volume:2ml~200ml
- Specialize for the PE/PP/PVC
MODEL | UNIT |
PK42HS |
PK42HD |
|
---|---|---|---|---|
Material To Be Used | PE/PP | PVC | PE/PP | |
PRODUCT | ||||
Product Volume (Min/Max) | cc | 20-200 | 20-100 | |
Product Dia. (Min/Max) | mm | 15-100 | 10-60 | |
Product Max. Weight | g | 60 | 30 | |
EXTRUDER | ||||
Screw Diameter | mm | 42 | 42 | |
L / D | 1:22 | 1:22 | ||
Screw-speed Range (PE/PP) | RPM | 15-85 | 15-85 | |
Induction Motor + Inverter (PE/PVC) | HP | 10-60 | x | |
Extruding VS Motor | HP | 7.5 | 10 | 7.5 |
Max. Extruding Output/Per Hour | kgs | 15 | 20 | 15 |
Barrel Heating Zone | zone | 2 | 2 | |
Barrel Heating Capacity | kw | 3 | 3 | |
DIE HEAD | ||||
Twin Cavity Center Distance | mm | x | 100 | |
Heating Zone | zone | 3 | 4 | |
Heating Capacity | kw | 2.8 | 2.6 | 4.6 |
MOLD PLATEN | ||||
Max. Opening Stroke | mm | 230 | 230 | |
Min. Claming Stroke | mm | 85 | 85 | |
HYDRAULIC SYSTEM | ||||
Pump Motor | HP | 5HPx6P | 5HPx6P | |
Pump Pressure | kg/cm² | 120 | 120 | |
Oil Tank Capacity | gallon | 30 | 30 | |
Total Power Consumption | kw | 15.2 | 15 | 16.8 |
Average Power Consumption | kw | 10.6 | 10.5 | 11.7 |
Machine Weight | Ton | 1.5 | 1.5 | |
Packing Size (LxWxH) | inch | 79"x89"x69" | 79"x89"x69" | |
Machine Meas't | M³ | 8 | 8 |
* All specifications and designs are subject to change without notice.
