PET STRETCH BLOW MOLDING MACHINE - THE WORLD'S MOST ENERGY EFFICIENT BOTTLE PRODUCTION LINE (EM STANDARD SERIES)
Classification : PET BLOW MOLDING MACHINE
KEENPRO INDUSTRY CORP.
Phone: 886-4-23345536/ 86-595-88169879
Fax: 886-4-23345539/ 86-595-88165687
Contact Person: Claire
- Adopt the touch screen control system with 64K color and friendly PLC operation.
- Exclusively designed machine construction makes it convenient to combine the blow molding machine with conveyor system.
- The preforms are automatically arranged in order for feeding system at a single way and the dividing carrier is driven by a servo motor; this way will avoid preforms jamming, causing machine down or preforms waste.
- Adopt a servo control screw driving system; it is rapid, stable, clean and environmentally friendly.
- The preforms are fed into the heating system in a matrix mode and uniform heated by single-lamp with double-sided heating.
- Employ a single-lamp with double-side heating design and will save about 50% heating consumption compared with competitor method.
- With the temperature feedback function, temperature in the heating oven is automatically controlled by adjustment of infrared lamps to reduce prefrom crystallization problems.
- Specially designed heating box upgrade convenience of maintenance in changing infrared lamp and cooling ramp.
- The clamping mechanism is driven by a combination of servo motor and cam; this results in accurate and stable motion, low noise and minimal pollution.
- Utilizes the air recovery system and efficiency up to 50% so that the low-pressure air compressor will not be required. This will save equipment investment costs and energy consumption by up to 15%.
|Preform neck||Max. (mm)||38||38||38||38||38||38||38|
|Preform height||Max. (mm)||100||100||100||100||160||160||160|
|Bottle diameter||Max. (mm)||80||70||70||80||115||115||115|
|Bottle height||Max. (mm)||262||240||240||262||320||320||320|
