PET Semi-Auto Stretch Blow Molding Machine

Classification : Stretch Blow Molding

CHIA MING MACHINERY CO., LTD.

Country: Taiwan

Phone: 886-4-22332281

Fax: 886-4-22306247

Contact Person: Sales Department

Inquiry Now

Small size and compact construction with no space waste. It is suitable for small and medium scale factories.
Easy to operate and maintain.
The machine adopts revolving infrared pre-heat system, it ensures PET preforms be heated evenly.

Model			CMH-1000B	CMH-1000C
Container	Max. neck diameter	mm	Ø15~Ø120	Ø28~Ø150
	Max. production capacity	pcs/hr	450~900	60~120
	Max. body diameter	mm	40~180	280
	Max. container height	mm	350	500
	Max. bottle capacity	ml	5000	25000
	No. of cavity	no.	1~2	1
Mould	Carry pitch	mm	-	-
	Mould center distance	mm	130±10	-
	No. of preform mandrels	pcs	13~20	-
Heating oven	No. of even	no.	4	4
	No. of infrared heaters in each oven	no.	8	8~13
	Heating load (max.)	kw	32	48~104
Air pressure	Low pressure	kg/cm2	7	7
Air pressure	High pressure	kg/cm2	35	35
Cooling water	Cooling capacity	kcal/h	12000	20000
	Water consumption	l/min	70	120
	Water temperature	°C	10~12	10~12
	Pressure	bar	5	5
Total consumption power		kw	35	52~107
Machine dimension		mm	1.85x1.03x2.3(heating)	2.74x1.03x2.3(heating)
Machine dimension		mm	1.7x0.87x2.3(blowing)	1.7x0.87x2.3(blowing)
Machine weight		ton	2	2.5
