Fully Automatic High Speed 2 Lines With Core Bag on roll Making Machine / SCR-40/ SCR-50

Classification : Bag on roll Making Machines
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
Video Inquiry Now
  • Computer control over the entire process
  • Servo motor, as standard attachment, makes it easy to adjust the bag length and the production speed
  • Automatic film feeding, coordination free from tension adjustment
  • Automatically stop when running out of film
  • Automatically stop when film feeding blocks or bags jam
  • Automatically stop when color scanning misses
  • High production efficiency to save manpower and time
  • Antomcatically core changing
Model SCR-40
Bag length 150 - 750 mm
Bag width 100 - 350 mm
Film Thickness 0.008 - 0.035 mm / layer
Production speed 100 meters / min / line
Finished Roll size Ø 180 x 350 mm (max)
Upload Film Roll Siza Ø 900 x 350 mm (max)
Core Size  Ø 25 ~ 75 mm, thickness 3 mm (min)
Power 220V, 3Phases, 50/60HZ, 18KVA
Heater 3.5 KW
Dimension L x W x H 6280 x 2400 x 1920 mm
Packing (L x W xH) Machine : 2880 x 1610 x 1510 mm
Rewinder : 2260 x 2580 x 1880 mm
Required Air Compressor 5HP (not included)
Weight 4000kg (net) / 4200kg (gross)
