Economical High-Speed Blown Film Machine
Categories : Blown Film Extruders Lines
Cost-Effective, High-Speed Solution for T-Shirt Bags and Garbage Bags The KS-E45 Economical High-Speed Blown Film Machine is a practical and cost-efficient solution developed by KUNG HSING Plastic Machinery for manufacturers producing T-shirt bags and garbage bags.Designed with simplicity, reliability, and high take-up speed in mind, the KS-E55 enables stable thin-film production at low investment cost, making it an ideal entry-level or capacity-expansion machine for bag manufacturers.
Dual-Die High-Speed Blown Film Machine
Categories : Blown Film Extruders Lines
Dual Die Design × Stable Speed × High-Efficiency Bag Production Solution The KS-E55S Dual-Die High-Speed Blown Film Machine is a high-efficiency production line developed by KUNG HSING Plastic Machinery for general packaging bag applications. Featuring a dual die head configuration, the KS-E55S significantly increases total output while maintaining a stable production speed. This design allows manufacturers to meet production targets without pushing a single die to extreme speeds—ensuring smoother operation and reducing operator pressure on the shop floor. By distributing output across two die heads, the machine delivers high productivity with stable line speed, enabling operators to work efficiently without being overwhelmed during winding and downstream processes.
High Speed Double Head Blowing Film Line
Categories : Blown Film Extruders Lines
High Speed Double Head Blowing Film Line
3 Layer Co-Extrusion Inflation Machine (GF-L3C-MT)
Categories : Blown Film Extruders Lines
The GF-L3C-MT is an A-B-C three-layer co-extrusion blown film line. Three extruders feed a co-extrusion die so that the inner, middle and outer layers of the film can be built from different resins, which is how a single film gains properties such as strength from one layer and sealability or surface finish from another. JANDI'S specifies the line for LDPE, LLDPE, mLLDPE, HDPE, EVA and PP. The MT configuration is built for wide flat film and gusseted film, with the film width and gusset width stated in the specification table below. Line configuration, film thickness range and downstream equipment are specified with the buyer at quotation, so the MT should be treated as a platform that JANDI'S tailors to the bag or packaging film the customer produces rather than a fixed catalog item. Type: A-B-C 3 layer co-extrusion blown film line Materials: LDPE / LLDPE / mLLDPE / HDPE / EVA / PP Model: GF-L3C-MT Film width and gusset width: see specification table Downstream configuration specified at quotation
Multi-Layer Coextrusion Zipper Blown Film Machine (AEZ-3L)
Categories : Blown Film Extruders Lines
MULTI-LAYER COEXTRUSION ZIPPER BLOWN FILM MACHINE
Blown Film Machine - MIDI Series
Categories : Blown Film Extruders Lines
Model: ● MIDI-40H ● MIDI-45H ● MIDI-40L ● MIDI-45L
TWO COLOR super high speed blown film line
Categories : Blown Film Extruders Lines
TWO COLOR super high speed blown film line
ABC THREE LAYER CO-EXTRUSION SUPER HIGH SPEED BLOWN FILM LINE
Categories : Blown Film Extruders Lines
ABC THREE LAYER CO-EXTRUSION SUPER HIGH SPEED BLOWN FILM LINE
LD/LLDPE Super High Speed Inflation Machine (GF-L85ES)
Categories : Blown Film Extruders Lines
The GF-L85ES is the largest of the three GF-L ES super high speed blown film lines for LD and LLDPE film. It is specified for a maximum film width of 2200 mm and a maximum capacity of 240 KG/HR, using an 85 mm screw, a 100 HP driving motor and a 500 mm blown film die, with 8 ZONES of temperature control on the panel. The GF-L55ES and GF-L65ES cover the narrower widths in the same series. The tower fixed take-up unit has a 2300 mm roller width and runs at Max. 60 M/Min, and the single-station surface friction winder changes bobbins semi-automatically by pneumatic system. The same option list as the rest of the ES series applies, including stacked air ring, width control, corona treater, EPC or CPC edge control, oscillating take-up, double station winder, auto tension control, hydraulic unloading, heat-slitting, a second gusset unit, an in-line bag making or printing machine, and an edge-trim on-line re-use system for returning trim to the extruder. Material: LD/LLDPE Max. film width: 2200 mm Max. capacity: 240 KG/HR Extruder: 85 mm screw, 100 HP driving motor; 500 mm blown film die Temperature control: 8 ZONES Take-up: tower fixed type, 2300 mm roller width, Max. 60 M/Min Winding: single station surface friction type, semi-auto pneumatic bobbin change Options: stacked air ring, width control, corona treater, EPC/CPC, oscillating take-up, double station winder, hydraulic unloading, heat-slitting, in-line bag making/printing, edge-trim re-use
PVA Water Soluble Blown Film Machine - GF-AV35.45
Categories : Blown Film Extruders Lines
The GF-AV35.45 listing covers JANDI'S PVA water soluble blown film machines in two extruder sizes, which differ in extruder diameter and maximum film width. Both process PVA based water soluble, compostable and biodegradable compounds into tubular film for water soluble bags and packaging. Each machine is supplied with an extruder, a blown film die, an air ring, a take-up tower and a winder. Options are an auto loader, manual screen changer, pressure gauge, die rotating unit, corona treater, flying knife, second station winder, air shaft and air chiller. The showroom specification table lists the film width and extruder size of each model; details are available with quotation and specifications can be changed on request. Type: PVA water soluble blown film machine, GF-AV35.45 listing Models: two extruder sizes, listed in the specification table Material: PVA based water soluble, compostable and biodegradable compounds Extruder, blown film die, air ring, take-up tower and winder Options: auto loader, manual screen changer, pressure gauge, die rotating unit Options: corona treater, flying knife, second station winder, air shaft, air chiller Film width and extruder size per model in the specification table
PLA/ PBAT Blown Film Machine
Categories : Blown Film Extruders Lines
The PLA/PBAT Blown Film Machine (GF-LB Series) is a blown film line configured for compostable and biodegradable resins based on PLA and PBAT. It produces tubular film from these compounds for downstream bag making, in the same way that JANDI'S GF-L series does for conventional polyethylene, and is listed in the showroom specification table as the GF-LB Series with film width and extruder size selected per model. The line is built from an extruder, a blown film die, an air ring, a take-up tower and a winder. Options include an auto loader, manual screen changer, pressure gauge, die rotating unit, corona treater, flying knife, second station winder, air shaft and air chiller. Film width, output and configuration are confirmed with the buyer at quotation; the specification table below lists the series range. Type: single-layer blown film machine, GF-LB Series Material: PLA/PBAT based compostable and biodegradable compounds Extruder, blown film die, air ring, take-up tower and winder Options: auto loader, manual screen changer, pressure gauge, die rotating unit Options: corona treater, flying knife, second station winder, air shaft, air chiller Film width and extruder size per model, confirmed at quotation
