Classification : Plastic Inflation Machine
Country: Taiwan
Phone: 886-2-22856880
Fax: 886-2-22856883
Contact Person: Gina Kang
KPP-45/55
Film Width100-520 mm
Screw Dia.Ø 45 mm
Suitable MaterialP.P.
KPP-45/55 model High-speed PP Blown Film Extrusion Line
| MODEL | KPP-45 | KPP-55 |
| SUITABLE MATERIAL | P.P. | P.P. |
| FILM THICKNESS | 0.02-0.1 mm | 0.025-0.1 mm |
| FILM WIDTH RANGE | 400 mm | 520 mm |
| FILM OUTPUT | 18-25 kgs/hr | 22-45 kgs/hr |
| EXTRUDER UNIT | ||
| SCREW DIAMETER/TYPE | Ø 45 mm | Ø 55 mm |
| SCREW L/D RATIO | 28:1 | 28:1 |
| HEATING CAPACITY | 9.6 kw | 13.1 kw |
| AUTO THERMO CONTROL | 4 zone | 4 zone |
| BARREL COOLING FAN | 1/16 HP x 2 | 1/16 HP x 2 |
| DRIVING MOTOR | AC 15 HP + Inverter | AC 20 HP + Inverter |
| DIE UNIT | ||
| DIE DIAMETER | Ø150 mm | Ø250 mm |
| AIR RING DIAMETER | Ø250 mm | Ø350 mm |
| HEATING CAPACITY | 3.3 kw | 6.5 kw |
| AUTO THERMO CONTROL | 2 zone | 2 zone |
| COOLING BLOWER | 1 HP | 1 HP |
| WATER RING | 10 pcs | 10 pcs |
| TAKE-UP UNIT | ||
| TAKE-UP ROLLER | 500 mm | 660 mm |
| EFFECTIVE WIDTH | 400 mm | 520 mm |
| TAKE-UP MOTOR | AC 1/2 HP | AC 1 HP |
| TAKE-UP SPEED | 40 m/min | 40 m/min |
| WINDING UNIT | ||
| ROLLER WIDTH | 500 mm | 660 mm |
| WINDING WIDTH | 400 mm | 520 mm |
| WINDING MOTOR | DC 1/2 HP | DC 1/2 HP |
| MACHINE DIMENSION | 400x120x370 cm | 450x180x425 cm |
* Remark: The above machine specification and production range can be changed without any notice due to kind of different application.
