HDPE / LDPE / LLDPE (A/B/A) TWO LAYER : KMTL-50S

Classification : Plastic Inflation Machine

Applications: Packaging Car Film Food Packaging Courier Bags

KANG CHYAU INDUSTRY CO., LTD.

Country: Taiwan

Phone: 886-2-22856880

Fax: 886-2-22856883

Contact Person: Gina Kang

Inquiry Now

The KMTL-50S is a 2-layer ABA blown film extrusion line for HDPE, LDPE, and LLDPE film, used in applications such as car film, food packaging, and courier bags.

The extruder unit runs Ø 50mm ×2 screws with a 30:1 L/D ratio and 25.8 kw of heating capacity across 8 auto thermo zones, feeding a rotating die (die diameter H: 100/150 mm, A/B/A) with a Ø 165 mm air ring for bubble cooling. A servo-driven take-up (1.5 kw) and winding unit (1 kw) handle the film at speeds up to 100 m/min, producing film from 0.010-0.15 mm thick and up to 1200 mm wide.

KMTL-50S

Film Width500-1200 mm

Screw Dia.Ø 50 mm*2

Suitable MaterialHDPE/LDPE/LLDPE

KMTL-50S model ABA 2-layer HDPE/LDPE/LLDPE Blown Film Extrusion Line

MODEL	KMTL-50S
SUITABLE MATERIAL	HDPE / LDPE / LLDPE
FILM THICKNESS	0.010-0.15 mm
FILM WIDTH RANGE	1200 mm
FILM OUTPUT	90-140 kgs/hr
EXTRUDER UNIT
SCREW DIAMETER/TYPE	Ø 50mm×2
SCREW L/D RATIO	30:1
HEATING CAPACITY	25.8 kw
AUTO THERMO CONTROL	8 zone
BARREL COOLING FAN	1/8 HP×6
DRIVING MOTOR	AC 30 HP + Inverter
DIE UNIT
DIE DIAMETER	H: 100/150 mm (A/B/A)
AIR RING DIAMETER	H: Ø 165 mm
HEATING CAPACITY	14 kw
AUTO THERMO CONTROL	3 zone
COOLING BLOWER	7.5 HP
TAKE-UP UNIT
TAKE-UP ROLLER	1300 mm
EFFECTIVE WIDTH	1200 mm
TAKE-UP MOTOR	SERVO 1.5 kw
TAKE-UP SPEED	100 m/min
TAKE-UP UNIT
ROLLERWIDTH	1300 mm
WINDING WIDTH	1200 mm
WINDING MOTOR	SERVO 1 kw
EQUIPMENT
ROTATING DIE
