Highly impact resistance and gloss
ABS resins offer excellent impact strength, heat and oil resistance, high gloss, and easy processing. They are suitable for electrical appliances, vehicles, articles for daily use and toys. GRECO, ABS Series are applied to EU chemicals policy (REACH regulation).
ISOPAK®569P
Item Name | ISOPAK®569P |
---|---|
Main Application | Good for Thermo-Forming, Suitcase industry, Tube, Plate, Safety helmet |
Package | 25 kg |
PROPERTIES | Test Method | Test Condition | Unit | Value |
---|---|---|---|---|
IZOD Impact Strength (Notched) |
D256 Method A |
23℃ 1/8¨x1/2¨x5/2¨ |
kg-cm/cm | 50 |
Melt Flow Index | D1238 |
220℃, 10kg/cm2 200℃, 5kg/cm2 |
g/10mins g/10mins |
5 0.5 |
Tensile Strength | D638 |
23℃, 1/8¨ 5.0mm/min |
kg/cm2 MPa |
425 33 |
Flexural Strength | D790 |
23℃ 2.8mm/min |
kg/cm2 Mpa |
600 59 |
Heat Distortion Temp. | D648 |
18.56kg/cm2 1/2¨x1/2¨x5¨ Unannealed |
℃ | 87 |
Rockwell Hardness | D785 | 23℃ | R Scale | 103 |
Specific Gravity | D792 | 23℃ | 1.03 | |
Flammability | UL-94 | 1/16¨ sample | HB |
ISOPAK®569E
Item Name | ISOPAK®569E |
---|---|
Main Application | Suitcase industry, Tube, Plate, Safety helmet |
Package | 25 kg |
PROPERTIES | Test Method | Test Condition | Unit | Value |
---|---|---|---|---|
IZOD Impact Strength (Notched) |
D256 Method A |
23℃ 1/8¡ x1/2¡ x5/2¡ |
kg-cm/cm | 38 |
Melt Flow Index | D1238 | 220℃, 10kg/cm2 | g/10mins | 9.0¡1.0 |
Tensile Strength at Yield at Break |
D638 |
23℃, 1/8¡ 5.0mm/min |
kg/cm2 |
410 360 |
Flexural Yield | D790 |
23℃ 2.8mm/min |
kg/cm2 | 600 |
Heat Distortion Temp. | D648 |
18.56kg/cm2 1/2¡ x1/2¡ x5¡ Unannealed |
℃ | 86 |
Rockwell Hardness | D785 | 23℃ | R Scale | 102 |
Specific Gravity | D792 | 23℃ | 1.03 | |
Flammability | UL-94 | 1/16¡ sample | HB |
