Classification : WASTE PLASTIC RECYCLING PELLETIZER
Country: Taiwan
Phone: 886-4-26627809
Fax: 886-4-26627590
Contact Person: Ted Kao
Model | KEM-100 | KEM-120 | KEM-130 | KEM-150 | |
Extruder Machine |
Screw Dia. | (L/D 30) | (L/D 32) | (L/D 32) | (L/D 32) |
Motor (3 Phase A.C.) | 50HP | 30HP | 60HP | 75HP | |
Automotic Therom-Controller | 6 SETS | 7 SETS | 7 SETS | 7 SETS | |
Heater | 24KW | 30KW | 30KW | 50KW | |
Speed Range | 2 | 2 | 2 | 2 | |
Force-Feed Motor | 5HP V.S | 5HP V.S | 5HP V.S | 5HP V.S | |
Hydraulic Motor | 3HP | 3HP | 3HP | 3HP | |
Capacity (per hour) | 120-200KG | 150-230KG | 150-300KG | 280-400KG | |
Machine | Screw Dia. | (L/D 8) | (L/D 8) | (L/D 8) | (L/D 8) |
Machine Motor | 15HP V.S. | 20HP V.S. | 20HP V.S. | 25HP V.S. | |
Heater | 8KW | 10KW | 10KW | 15KW | |
Cooling Tank | 3M | 3M | 3M | 3M | |
Wet Absorbing Machine 2HP | - | - | - | - | |
Motor of Granule Machine | 3HP | 5HP | 5HP | 7.5HP | |
5HP Blower | - | - | - | - | |
1000L Storage Tank | - | - | - | - | |
Operating Range | 5M x 12M | 5M x 13M | 5M x 14M | 5M x 12M | |
Weight of the Machine | 3200KG | 4600KG | 4800KG | 5200KG | |
Packing Measurement (LxWxH) |
4M x 1.5M x 1.5M | 4M x 1.5M x 1.5M | 4M x 1.5M x 1.5M | 5.5M x 2M x 2M |
