All Electric Injection Machine KET100R (ROTARY TABLE)

Classification : All Electric Injectiom Machine - KET Series

TAIWAN KINKI MACHINERY CO., LTD.

TAIWAN KINKI MACHINERY CO., LTD.
Country: Taiwan
Phone: 886-2-2281-3361
Fax: 886-2-2281-8206
Contact Person: Terry Hsieh
  • All Electric Injection Machine
  • END PRODUCTS: This machine could produce Hardware & Household Item and so on

Machine Type Unit KR-85-D(R) KR-110-D(R) KR-150-D(R)
Screw Diameter mm 20 25 25 30 30 35
Injection Pressure kg/cm2 2500 1836 2500 1736 2500 1600
Theoretical Shot Volume cm3 31 49 59 85 99 135
Max. Shot Weight(PS) g 29 45 54 77 90 123
Injection Speed(High Loading Capacity) mm/sec 200 200 200
Injection Speed(High Velocity) mm/sec 270 270 270
Screw Stroke mm 100 120 140
Screw Speed Max. rpm 350 350 350
Nozzle Contact Force tons 2 2.4 2.6
Nozzle Retraction Stroke mm 200 250 280
Number of Temperature Control - 3 3 4
Material Hopper Capacity | 20 20 30
Machine Type Unit KET-40R KET-70R KET-100R
Clamping Force tons 40 70 100
Dimensions of Rotary Table mm 1000 1200 1400
Mold Thickness mm 170~270 230~350 250~400
Opening Stroke mm 210 250 270
Ejector Force tons 1.3 2.1 2.6
Ejector Stroke mm 60 60 60
Machine Type Unit KET-40R KET-70R KET-100R
Heater Capacity kw 2.7 3.5 4.5
Consumption kw 14.6(30Ax380V) 18(50Ax380V) 20(75Ax380V)
Machine Weight tons 3 4 7.5
Machine Dimensions(L x W x H) m - - -
