Twin Head ABA HDPE / LDPE / LLDPE Plastic Inflation Machine KMTL-T Series

MODEL	KMTL-4545T
SUITABLE MATERIAL	HDPE/LDPE/LLDPE
FILM THICKNESS	0.010-0.15 mm
FILM WIDTH RANGE	400 mm x 2
FILM OUTPUT	10-32 kgs/hr x 2
EXTRUDER UNIT
SCREW DIAMETER/TYPE	Ø 45mm x 2
SCREW L/D RATIO	28:1
HEATING CAPACITY	18.8 kw
AUTO THERMO CONTROL	6 zone
BARREL COOLING FAN	1/8 HP x 4
DRIVING MOTOR	AC 20 HP + Inverter
DIE UNIT
DIE DIAMETER	ABA: Ø60/80 mm x 2
AIR RING DIAMETER	H: Ø120 mm x 2
HEATING CAPACITY	30.8 kw
AUTO THERMO CONTROL	10 zone
COOLING BLOWER	3 HP x 2
TAKE-UP UNIT
TAKE-UP ROLLER	760 mm
EFFECTIVE WIDTH	660 mm
TAKE-UP MOTOR	AC 1/2 HP
TAKE-UP SPEED	85 m/min
WINDING UNIT
ROLLER WIDTH	760 mm
WINDING WIDTH	660 mm
WINDING MOTOR	DC 1/2 HP

* Remark: The above machine specification and production range can be changed without any notice due to kind of different application.
