STRETCH FILM LDPE/LLDPE PLASTIC INFALATION MACHINE KML-S Series

Classification : Plastic Inflation Machine

KANG CHYAU INDUSTRY CO., LTD.

KANG CHYAU INDUSTRY CO., LTD.
Country: Taiwan
Phone: 886-2-22856880
Fax: 886-2-22856883
Contact Person: Gina Kang

SUITABLE MATERIAL: LDPE/LLDPE


KML-45S/55S

Film Width: 500-900 mm
Screw Dia.: Ø 45/55 mm



MODEL KML-45S KML-55S
SUITABLE MATERIAL LDPE/LLDPE LDPE/LLDPE
FILM THICKNESS 0.008-0.10 mm
0.008-0.10 mm
FILM WIDTH RANGE 600 mm 900 mm
FILM OUTPUT 20-55 kgs/hr 30-72 kgs/hr
EXTRUDER UNIT
SCREW DIAMETER/TYPE Ø 45mm Ø 55mm
SCREW L/D RATIO 30:1 30:1
HEATING CAPACITY 9.8 kw 14 kw
AUTO THERMO CONTROL 4 zone 4 zone
BARREL COOLING FAN 1/8 HP x 2 1/8 HP x 3
DRIVING MOTOR AC 20 HP + Inverter AC 30 HP + Inverter
DIE UNIT
DIE DIAMETER Ø175 mm Ø250 mm
AIR RING DIAMETER Ø225 mm
Ø300 mm
HEATING CAPACITY 6.5 kw 9 kw
AUTO THERMO CONTROL 2 zone 3 zone
COOLING BLOWER 3 HP + Inverter 5 HP + Inverter
TAKE-UP UNIT
TAKE-UP ROLLER 760 mm 1100 mm
EFFECTIVE WIDTH 660 mm 900 mm
TAKE-UP MOTOR AC 1/2 HP AC 1/2 HP
TAKE-UP SPEED 75 m/min 65 m/min
ELEVATING MOTOR Roller Type
WINDING UNIT
ROLLER WIDTH 760 mm 1100 mm
WINDING WIDTH 660 mm 900 mm
WINDING MOTOR DC 1/2 HP x 3 DC 1/2 HP x 3
EQUIPMENT Auto tension controller
Waste collection winder
Adhesives auto - feeder
Auto tension controller
Waste collection winder
Adhesives auto - feeder
* Remark: The above machine specification and production range can be changed without any notice due to kind of different application.
