Roll-On Ball / Hollow Ball Making Machine- CM - 800WJL Series

Classification : Extrusion Blow Molding

CHIA MING MACHINERY CO., LTD.

Country: Taiwan

Phone: 886-4-22332281

Fax: 886-4-22306247

Contact Person: Sales Department

Inquiry Now

Our hollow balls are produced by blow molding techniques which deliver the advantage of strength and a substantial reduction in material weight.

This process offers significant cost savings over solid balls with no functional differences, virtually every roll-on deodorant manufacturer in the world uses the hollow ball.

The plastic ball easily rolls an even and effective layer of the product onto the skin.

Model		CM-65DH
Model	Material to be Used		PE/PP
	Screw Diameter	mm	Ø65
	L/D Ratio		24/1
	Screw Speed Range (PE)/rpm	rpm	15-65
	Inverter Motor	HP	20
	Max. Extrusive Capacity/Hour	kgs	60
	Heating Zone (Barrel)	zone	3
	Heating Capacity (Barrel)	kw	10.8
Die head	Heating Zone (Diehead)	zone	3
	Heating Capacity (Diehead)	kw	11.9
	Double Mold Center Distance	mm	140
Mold Plate	Max. Opening Stroke	mm	550
	Min. Close Stroke	mm	172
	Mold Clamping Force	ton	7.5
Hydraulic System	Hydraulic Pump Motor	HP	15
	Hydraulic Oil Pressure	kg/cm2	100
	Oil Tank Capacity	gallon	85
Product	Product Weight (Max.)	g	140
	Product Dia. (Min./Max.)	mm	50-110
	Product Capacity (Min./Max.)	ml	500-2000
	Total Power Consumption	kw	52.6
	Weight of Machine	ton	6

* All Specifications and designs are subject to change without notice.
* All models can be upgraded to hybrid or fully electric type by servo motor control.
