Classification : Mono/Multi Layer Sheet Making Machines
Country:
Phone: 886-6-2532157
Fax: 886-6-2533079
Contact Person: Susan Wei
Resin |
PA6, PA66, PP |
Product |
Sticky buckle strap |
Product thickness |
0.4-2.0 mm |
Product width |
320 mm (trimmed) |
Capacity |
130 kg/hr for PA |
Line speed |
30 m/min |
Extruder |
65 mm dia , L/D=34 |
Main drive |
75 HP A.C. invertor motor |
Extrusion die |
FKI made |
Screen changer |
hydraulic type |
Line Speed |
2 - 12 M/Min. (Max.) |
Polishing roller |
φ 254 MM x 556 MM wide x 1 φ 254 MM x 500 MM wide x 2 |
Gap adjustment |
Driven by hydraulic unit /Controlled by Servo motor |
Take off unit |
φ 150 M/M dia. x 500 M/M wide x 2 |
Winder |
turret type |
Electric cabinet |
one set |
