LDPE/LLDPE HIGH SPEED PLASTIC INFLATION MACHINE KML Series

Classification : Plastic Inflation Machine

KANG CHYAU INDUSTRY CO., LTD.

KANG CHYAU INDUSTRY CO., LTD.
Country: Taiwan
Phone: 886-2-22856880
Fax: 886-2-22856883
Contact Person: Gina Kang

SUITABLE MATERIAL: LDPE/LLDPE


KML-25

Film Width: 100-150 mm
Screw Dia.: Ø 25 mm


KML-35

Film Width: 100-500 mm
Screw Dia.: Ø 35 mm


KML-45/55

Film Width: 400-1000 mm
Screw Dia.: Ø 45/55 mm


KML-65

Film Width: 400-1400 mm
Screw Dia.: Ø 65 mm


KML-80

Film Width: 500-2000 mm
Screw Dia.: Ø 80 mm


KML-120

Film Width: 1800-3000 mm
Screw Dia.: Ø 120 mm


MODEL KML-25 KML-35 KML-45 KML-55 KML-65 KML-80 KML-120
SUITABLE MATERIAL LDPE/LLDPE LDPE/LLDPE LDPE/LLDPE LDPE/LLDPE LDPE/LLDPE LDPE/LLDPE LDPE/LLDPE
FILM THICKNESS 0.015-0.10 mm 0.015-0.15 mm 0.02-0.15 mm 0.02-0.15 mm 0.025-0.15 mm 0.03-0.15 mm 0.05-0.15 mm
FILM WIDTH RANGE 150 mm 500 mm 650 mm 400-1000 mm 400-1400 mm 2000 mm 1800-3000 mm
FILM OUTPUT 5-15 kgs/hr 10-30 kgs/hr 20-55 kgs/hr 30-72 kgs/hr 50-105 kgs/hr 200 kgs/hr 280 kgs/hr
EXTRUDER UNIT
SCREW DIAMETER/TYPE Ø 25 mm Ø 35mm Ø 45mm Ø 55mm Ø 65mm Ø 80mm Ø 120mm
SCREW L/D RATIO 26:01:00 26:01:00 26:01:00 26:01:00 26:01:00 30:01:00 30:01:00
HEATING CAPACITY 3.6 kw 5.2 kw 8.6 kw 12 kw 14.7 kw 22.1 kw 53 kw
AUTO THERMO CONTROL 2 zone 3 zone 3 zone 3 zone 4 zone 7 zone 8 zone
BARREL COOLING FAN   1/16 HP x 1 1/16 HP x 2 1/8 HP x 2 1/8 HP x 2 1/8 HP x 5 1/8 HP x 7
DRIVING MOTOR AC 3 HP + Inverter AC 10 HP + Inverter AC 20 HP + Inverter AC 30 HP + Inverter AC 50 HP + Inverter AC 75 HP + Inverter AC 150 HP + Inverter
DIE UNIT
DIE DIAMETER Ø40 mm Ø100 mm Ø150 mm Ø200 mm Ø350 mm Ø500 mm Ø750 mm
AIR RING DIAMETER Ø100 mm Ø150 mm Ø200 mm Ø250 mm Ø400 mm Ø550 mm Ø800 mm
HEATING CAPACITY 1.6 kw 2.9 kw 5 kw 7 kw 14.4 kw 29.8 kw 63 kw
AUTO THERMO CONTROL 1 zone 1 zone 2 zone 2 zone 2 zone 3 zone 4 zone
COOLING BLOWER 1 HP 2 HP 3 HP 5 HP 5 HP 10 HP 10 HP
TAKE-UP UNIT
TAKE-UP ROLLER 200 mm 660 mm 760 mm 1100 mm 1500 mm 2200 mm 3200 mm
EFFECTIVE WIDTH 150 mm 550 mm 660 mm 1000 mm 1400 mm 2000 mm 3000 mm
TAKE-UP MOTOR AC 1/2 HP AC 1/2 HP AC 1/2 HP AC 1/2 HP AC 1 HP AC 2 HP AC 3 HP + Inverter
TAKE-UP SPEED 45 m/min 75 m/min 75 m/min 55 m/min 45 m/min 45 m/min 22 m/min
ELEVATING MOTOR
WINDING UNIT
ROLLER WIDTH 200 mm 660 mm 760 mm 1100 mm 1500 mm 2200 mm 3200 mm
WINDING WIDTH 150 mm 550 mm 660 mm 1000 mm 1400 mm 2000 mm 3000 mm
WINDING MOTOR 12 kgs-cm DC 1/2 HP DC 1/2 HP DC 1 HP DC 1 HP DC 2 HP DC 3 HP
MACHINE DIMENSION 150×70×250 cm 400×120×380 cm 470×165×400 cm 500×220×450 cm 800×400×630 cm 800×500×900 cm 16.5×7×10 m
* Remark: The above machine specification and production range can be changed without any notice due to kind of different application.
