HDPE HIGH SPEED PLASTIC INFLATION MACHINE KMH Series

Classification : Plastic Inflation Machine

KANG CHYAU INDUSTRY CO., LTD.

KANG CHYAU INDUSTRY CO., LTD.
Country: Taiwan
Phone: 886-2-22856880
Fax: 886-2-22856883
Contact Person: Gina Kang

SUITABLE MATERIAL: HDPE


KMH-MINI

Film Width: 100-550 mm
Screw Dia.: Ø 40 mm


KMH-35

Film Width: 100-400 mm
Screw Dia.: Ø 35 mm


KMH-45/55

Film Width: 100-900 mm
Screw Dia.: Ø 45/55 mm


KMH-65

Film Width: 500-1300 mm
Screw Dia.: Ø 65 mm


MODEL KMH-MINI KMH-35 KMH-45 KMH-55 KMH-65
SUITABLE MATERIAL HDPE HDPE HDPE HDPE HDPE
FILM THICKNESS 0.008-0.10 mm 0.008-0.10 mm 0.008-0.10 mm 0.008-0.10 mm 0.008-0.10 mm
FILM WIDTH RANGE 550 mm 400 mm 650 mm 900 mm 1300 mm
FILM OUTPUT 15-32 kgs/hr 10-28 kgs/hr 10-42 kgs/hr 20-60 kgs/hr 20-80 kgs/hr
EXTRUDER UNIT
SCREW DIAMETER/TYPE Ø 40mm Ø 35 mm Ø 45mm Ø 55mm Ø 65 mm
SCREW L/D RATIO 26:01:00 26:01:00 26:01:00 26:01:00 26:01:00
HEATING CAPACITY 6.6 kw 5.7 kw 8.6 kw 12 kw 14.7 kw
AUTO THERMO CONTROL 3 zone 3 zone 3 zone 3 zone 4 zone
BARREL COOLING FAN 1/8 HP×1 1/8 HP×1 1/8 HP×2 1/8 HP×2 1/8 HP×2
DRIVING MOTOR AC 15 HP + Inverter AC 15 HP + Inverter AC 20 HP + Inverter AC 30 HP + Inverter AC 50 HP + Inverter
DIE UNIT
DIE DIAMETER Ø60/80 mm Ø50/80 mm Ø70/90 mm Ø80/100 mm Ø100/150 mm
AIR RING DIAMETER Ø120 mm Ø120 mm Ø120 mm Ø150 mm Ø150/200 mm
HEATING CAPACITY 6.6 kw 4.6 kw 6.1 kw 7.6 kw 10.6 kw
AUTO THERMO CONTROL 2 zone 1 zone 2 zone 2 zone 2 zone
COOLING BLOWER 3 HP 3 HP 3 HP 5 HP 5 HP
TAKE-UP UNIT
TAKE-UP ROLLER 660 mm 500 mm 760 mm 1100 mm 1500 mm
EFFECTIVE WIDTH 550 mm 400 mm 660 mm 1000 mm 1400 mm
TAKE-UP MOTOR AC 1/2 HP AC 1/2 HP AC 1/2 HP AC 1/2 HP AC 1 HP
TAKE-UP SPEED 85 m/min 85 m/min 85 m/min 75 m/min 75 m/min
ELEVATING MOTOR     AC 1/2 HP
WINDING UNIT
ROLLER WIDTH 660 mm 500 mm 760 mm 1100 mm 1500 mm
WINDING WIDTH 550 mm 400 mm 660 mm 1000 mm 1400 mm
WINDING MOTOR DC 1/2 HP DC 1/2 HP DC 1/2 HP DC 1 HP DC 1 HP
MACHINE DIMENSION 370×270×340 cm 350×260×310 cm 470×165×400 cm 500×200×400 cm 600×400×600 cm
* Remark: The above machine specification and production range can be changed without any notice due to kind of different application.
