- Vertical mold clamp with horizontal injection with long closing and opening stroke, ideal for injection of large work pieces.
- Extra heavy structure and large mold capacity along with simple and easy-to-use layout.
- Horizontal injection can be raised or lowered using hydraulic screws for fast, accurate positioning.
- There are few restrictions on the dimensions of molds or mold lines, and the range of applications is very broad.
- The platen uses self-lubricated axles which require no further lubrication, for smooth, easy movement and super-long useful life.
- Special functions for certain products can also be programmed, including strong clamping force, small injection quantities, faster injection rates, multiple die-sets, mold ventilation, mold vacuum and other operations.
- Other functions include insertion and cyclic finishing with a slide platen or rotary plate as needed.
Machine Type |
Unit |
KR-85-D(R) |
KR-110-D(R) |
KR-150-D(R) |
KR-225D(DM) |
KR-300D(DM) |
|||||
Screw Diameter |
mm |
38 |
42 |
45 |
50 |
52 |
62 |
62 |
70 |
70 |
80 |
Injection Pressure |
kg/cm2 |
1750 |
1434 |
1560 |
1262 |
2486 |
1748 |
1748 |
1371 |
1600 |
1225 |
Theoretical Shot Volume |
cm3 |
190 |
231 |
286 |
353 |
509 |
724 |
724 |
923 |
1154 |
1507 |
Max. Shot Weight(PS) |
g |
173 |
210 |
260 |
321 |
463 |
658 |
658 |
840 |
1038 |
1356 |
oz |
6.1 |
7.4 |
9.1 |
11.3 |
16.3 |
23 |
23 |
29.5 |
37.3 |
48.8 |
|
Injection Rate |
cm3/sec |
86 |
105 |
118 |
145 |
127 |
181 |
220 |
280 |
244 |
319 |
Screw Stroke |
mm |
168 |
180 |
240 |
240 |
300 |
|||||
Screw Speed Max. |
rpm |
0-175 |
0-160 |
0-142 |
0-126 |
0-126 |
|||||
Nozzle Contact Force |
tons |
3.9 |
6 |
6.7 |
6.7 |
6.7 |
|||||
Nozzle Retraction Stroke |
mm |
250 |
250 |
250 |
250 |
300 |
|||||
Number of Temperature Control |
- |
4 |
5 |
5 |
5 |
5 |
|||||
Material Hopper Capacity |
| |
40 |
40 |
90 |
90 |
90 |
Machine Type |
Unit |
KR-85-D(R) |
KR-110-D(R) |
KR-150-D(R) |
KR-225D(DM) |
KR-300D(DM) |
Clamping Force |
tons |
85 |
120 |
165 |
225 |
300 |
Opening Force |
tons |
14 |
18 |
29 |
14 |
34 |
Platen Size |
mm |
410x600 |
480x760 |
520x760 |
700x1030 |
900x1300 |
Distance Between Tie Bare |
mm |
1000x205 |
990x260 |
1180x260 |
720x390 |
1000x600 |
Min. Mold Height |
mm |
180 |
200 |
250 |
310 |
350 |
Opening Stroke |
mm |
250 |
250 |
350 |
350 |
400 |
Max. Open Daylight |
mm |
430 |
450 |
600 |
660 |
750 |
Ejector Force |
tons |
2.7 |
2.7 |
2.9 |
6 |
6 |
Ejector Stroke |
mm |
45/95 |
45/95 |
45/95 |
45/95 |
45/95 |
Machine Type |
Unit |
KR-85-D(R) |
KR-110-D(R) |
KR-150-D(R) |
KR-225D(DM) |
KR-300D(DM) |
Slide Stroke |
mm |
300/Ø980 |
400/Ø980 |
420/Ø1170 |
505/700 |
800/1600 |
Rotary Station |
- |
2-4 |
2-4 |
2-4 |
2 |
2 |
Max. Mold Weight |
kg |
200x2/140x3 |
350x2/240x3 |
450x2/300x3 |
700x2 |
1000x2 |
Station Accuracy |
mm |
±0.02 |
±0.02 |
±0.02 |
±0.02 |
±0.02 |
Machine Type |
Unit |
KR-85-D(R) |
KR-110-D(R) |
KR-150-D(R) |
KR-225D(DM) |
KR-300D(DM) |
Max. Hydraulic Pressure |
kg/cm2 |
140 |
175 |
175 |
175 |
175 |
Pump Output |
liters/min |
65-12 |
79-14 |
109-17 |
132-19 |
134-21 |
Oil Reservoir Capacity |
liters |
300 |
420 |
550 |
650 |
750 |
Cooling Water Consumption |
liters/hr |
800-1000 |
1000-1200 |
1400-1600 |
1800-2000 |
2200-2400 |
Pump Motor Power |
kw |
11 |
15 |
18.3 |
22 |
30 |
Barrel Heating Power |
kw |
7.5 |
10 |
14.3 |
14.3 |
18.6 |
Total Wattage |
kw |
18.5 |
25 |
32.6 |
36.3 |
48.6 |
Machine Type |
Unit |
KR-85-D(R) |
KR-110-D(R) |
KR-150-D(R) |
KR-225D(DM) |
KR-300D(DM) |
Machine Weight |
tons |
4.9 |
7 |
10.4 |
12 |
14 |
Machine Dimensions(L x W x H) |
m |
3.75x1.35x2.4 |
3.9x1.5x2.7 |
4.3x2.1x3.1 |
4.7x3.0x3.6 |
5.0x3.3x4.0 |
Shipping Weight |
tons |
5.5 |
7.8 |
11.4 |
13.2 |
15.2 |
Shipping Measurements(L x W x H) |
m |
4.1x1.5x2.3 |
4.4x1.7x2.6 |
4.8x2.3x3.0 |
5.2x3.2x3.3 |
5.5x3.5x3.7 |
