Classification : Bag on roll Making Machines
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
- Computer control over the entire process
- From film roll to final product, one process flow
- Automatic film feeding, cordination free from tension adjustment
- Automatically stop when running out of film / color scanning error / film feeding blocks or jam
MODEL | SBCR-750-OB |
Length | 200 ~ 1500 mm |
Width | 300 ~ 750 mm |
Thickness | 10 ~ 60 um |
Roll size | Ø 180 mm |
Core size | Ø 25 ~ 75 mm, thickness 3 mm (min) |
Production Speed | 100 meters / min / line (max) |
Film Roll Size | Ø 900 x 750 mm |
Power | 220V, 3Phases, 50/60 HZ, 12KVA |
Heater | 2.5 KW |
Dimension | L7450 mm x W1700 mm x H1950 mm |
